6 Ton Coal Fired Steam Boiler In Indonesia

ModelDZL series coal fired boiler

Capacity6 ton

Applicationsteam supply

case case case

Overview



Boiler Specification

Rated capacity: 6t/h
Steam pressure: 1.25Mpa
Steam temperature: 193.3℃
Rate outlet temperature: 105℃
Efficiency: 80.02%
Design fuel: bituminous coal+lignite coal

Packaged coal fired boiler exporter Indonesia

This boiler is steam boiler of horizontal type, single drum with traveling chain grate. The threaded gas pipe is inside the boiler drum, and both side water-cooling wall rounds thumb flue in drum’s belly. This structure protects effectively the boiler drum and avoids the belly directly radiated by fire. Boiler drum connects the two headers by two side water cooling wall. Four downcast pipes are fore-side and rearward of boiler drum, and every pipe is led from drum to header. By this design, the drum and headers becomes a circulation loop together with the two sides water-cooling walls.

Background

There are large quantity of coal, oil and other mineral resources in Indionesia. In order to meed the need of production, in June, 2013, a company in Jatim, Indonesia purchased one set of 6 ton coal fired steam boiler from our company. The packaged grate coal fired boiler is designed to burn lignite coal and bituminous coal with coal size of 1—40mm, and coal consumption is about 864.72Kg/h.

If you have any questions, please contact our Executive Manager and we will get back to you as soon as possible
