Figuring Out Boiler Horsepower



Boiler horsepower is not related to mechanical horsepower. It is a boiler industry rating that predicates the amount of saturated steam a boiler will generate starting with water at 212 degrees Fahrenheit and 0 pounds per square inch gauge (psig--meaning atmospheric pressure) and ending with steam at 212 F and 0 psig. For example, if a boiler is rated at 50 bhp, then it will produce 50 bhp x 34.5 pounds per hour (lb/hr) = 1,725 lb/hr of steam under these conditions.

BHP is still used to measure boiler output in industrial boiler engineering in North America. One Boiler Horsepower (1BHP) is equal to a bolier thermal output of 33 475 BTU/h (British Thermal Units per Hour) or 9.81055407 kW (Kilowatts). This is the energy rate required to evaporate 34.5 lb (pounds) or 15.648936765 kg (kilograms) of fresh water at 212 °F (degrees Fahrenheit) or 100 °C (Celsius) in one hour (1h).

About how to figure out boiler horsepower, boiler horsepower was used in USA, Australia, and New Zealand and have been calculated in different ways.
PBoHP = A / k
where
PBoHP = boiler horsepower
A = heat transfer area (ft2)
k = standard area (ft2)

Product dimensions and equipment levels are tailored to the customer's individual needs, no matter what industry you are engaged in, ZBG will be able to help you. More information about figuring out boiler horsepower or boiler horsepower conversion, please consult our online customer service.
