20 Ton Gas Steam Boiler in Paper Plant

Overview

Project: SZS20-1.25-Q boiler in paper production
Application area: steam providing in paper making
Project site: Huaxi Paper Co., Ltd.

20 ton coal gas fired boiler

Model: SZS20-1.25-Q
Capacity: 20 t/h
Steam Pressure: 1.25MPa
Steam temperature: 194℃
Feedwater temperature: 20℃
Design fuel: coal-gas

Why choose SZS gas fired steam boiler

There are two types of gas fired steam boilers: WNS series and SZS series. WNS is fire tube boiler and SZS is water tube boiler. Compared to WNS series, the SZS boiler can burn low-heat value fuel, like coal gas, biogas, blast furnace gas. What’s more, water tube boiler is more safer than a fire tube one. The 20 ton coal gas fired steam boiler has high thermal efficiency and low emission. Its packaged type layout saves occupied area and transportation cost.

Background

Large amounts of steam and power is needed in paper-making. Huaxi Paper Co., Ltd. recently purchased one set of gas steam boiler,SZS type watertube steam boiler, burning coal gas. The company has their own captive power plant burning coal fuel, and the coal fired power plant produces coal gas every day. The 20 ton steam boiler is designed to burn the coal gas as fuel.
